LINQSTAT Volume Conductive Film

CAPLINQ is primarily a business-to-business company, so the prices listed exclude all taxes.
The products listed are the most standard products widths available. Custom widths, lengths and thicknesses can be made to customer specifications. Contact us for a quotation. Prices are ex-works CAPLINQ and freight charges apply as follows:

• Europe, Middle East, Asia and Africa: ex-works CAPLINQ Netherlands (Amsterdam)
• Canada, USA, Mexico and South America: ex-works CAPLINQ Canada (Ottawa)

• Linqstat VCF S&V-Series (Compare Velostat 1704, 1706 & 1708)

  • No. of Rolls	Product Part No.	Dimensions (Thickness) x (Width) x (Length)			Price (USD$) per roll
    Roll Dimensions: 36" (91cm) wide x 150' (46m) long x 0.002" (0.05mm) thick Minimum Order Quantity - 1 roll
    1-4 5-9 10-24 25+	VCF-20036S/2 VCF-20036S/2 VCF-20036S/2 VCF-20036S/2	2 mil (50µm)	36" (91cm)	150' (46m)	ONLY $54.23/roll (was $65.08/roll) ONLY $47.45/roll (was $56.94/roll) ONLY $35.25/roll (was $42.30/roll) ONLY $27.11/roll (was $32.54/roll)
    Roll Dimensions: 36" (91cm) wide x 150' (46m) long x 0.00236" (0.06mm) thick Minimum Order Quantity - 1 roll
    1-4 5-9 10-24 25+	VCF-2C036S/2 VCF-2C036S/2 VCF-2C036S/2 VCF-2C036S/2	2.36 mil (60µm)	36" (91cm)	150' (46m)	ONLY $65.39/roll (was $78.46/roll) ONLY $56.05/roll (was $67.25/roll) ONLY $48.57/roll (was $58.25/roll) ONLY $37.36/roll (was $44.84/roll)
    Roll Dimensions: 1 ⅜" (35mm) wide x 650' (200m) long x 0.004" (0.1mm) thick Minimum Order Quantity - 50 rolls
    50 150	VCF-400013/8S/8 VCF-400013/8S/8	4 mil (100µm)	1 ⅜" (35mm)	650' (200m)	$40.68 $20.34
    Roll Dimensions: 9" (23cm) wide x 150' (46m) long x 0.004" (0.1mm) thick Minimum Order Quantity - 25 rolls
    25 100	VCF-40009S/2 VCF-40009S/2	4 mil (100µm)	9" (23cm)	150' (46m)	$46.41 $38.85
    Roll Dimensions: 36" (91 cm) wide x 150' (46m) long x 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll
    1-4 5-9 10-24 25+	VCF-40036S/2 VCF-40036S/2 VCF-40036S/2 VCF-40036S/2	4 mil (100µm)	36" (91cm)	150' (46m)	Click for Volume Breaks (compare to $210.18/roll)
    Roll Dimensions: 36" (91 cm) wide x 1500' (460m) long x 0.004" (0.1mm) thick Minimum Order Quantity - 2 rolls Save up to 35% per sq. ft on extra-long rolls!
    2 4 10	VCF-40036S/7 VCF-40036S/7 VCF-40036S/7	4 mil (100µm)	36" (91cm)	1500' (460m)	ONLY $1104.40/roll (was $1248.12/roll) ONLY $999.98/roll (was $1095.12/roll) ONLY $828.80/roll (was $1022.04/roll)
    Roll Dimensions: 54" (137 cm) wide x 150' (46m) long x 0.004" (0.1mm) thick Minimum Order Quantity - 5 meters V-Sheet (Folded in half) Buy it by the meter!
    Per meter 1-4 5+	VCF-40054V/m VCF-40054V/2 VCF-40054V/2	4 mil (100µm)	54" (137cm)	150' (46m)	Click for Volume Breaks Click for Volume Breaks
    Roll Dimensions: 36" (91cm) wide x 150' (46m) long x 0.008" (0.2mm) thick Minimum Order Quantity - 1 roll
    1-4 5-9 10-24 25+	VCF-80036S/2 VCF-80036S/2 VCF-80036S/2 VCF-80036S/2	8 mil (200µm)	36" (91cm)	150' (46m)	ONLY $187.50/roll (was $225.08/roll) ONLY $175.25/roll (was $210.08/roll) ONLY $162.50/roll (was $194.30/roll) ONLY $125.27/roll (was $153.54/roll)

• Linqstat VCF B-Series (Compare to Velostat 2004 & 2014)

  • No. of Boxes (100 Bags/Box)	Product Part No.	Dimensions (Thickness) x (Width) x (Length)			Price (USD$) per Box
    Bag Dimensions: 4" (10cm) wide x 6" (15cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 Box
    1-4 5-9 10-24 25+	VCF-40406B VCF-40406B VCF-40406B VCF-40406B	4 mil (100µm)	4" (10cm)	6" (15cm)	ONLY $11.10/box ONLY $10.50/box ONLY $10.25/box ONLY $10.05/box
    Bag Dimensions: 8" (20cm) wide x 10" (25cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 Box
    1-4 5-9 10-24 25+	VCF-40810B VCF-40810B VCF-40810B VCF-40810B	4 mil (100µm)	8" (20cm)	10" (25cm)	ONLY $19.98/box ONLY $19.80/box ONLY $17.10/box ONLY $16.65/box
    Bag Dimensions: 10" (25cm) wide x 14" (36cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 Box
    1-4 5-9 10-24 25+	VCF-41014B VCF-41014B VCF-41014B VCF-41014B	4 mil (100µm)	10" (25cm)	14" (36cm)	ONLY $33.60/box ONLY $31.20/box ONLY $29.60/box ONLY $28.80/box
    Bag Dimensions: 18" (46cm) wide x 24" (61cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 Box
    1-4 5-9 10-24 25+	VCF-41824B VCF-41824B VCF-41824B VCF-41824B	4 mil (100µm)	18" (46cm)	24" (61cm)	ONLY $92.84/box (was $221.22/box) ONLY $85.50/box (was $146.85/box) ONLY $81.45/box (was $132.17/box) ONLY $78.75/box (was $117.48/box)
    Bag Dimensions: 24" (61cm) wide x 24" (61cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 200 Bags
    1-4 5-9 20-24 25+	VCF-42424B VCF-42424B VCF-42424B VCF-42424B	4 mil (100µm)	24" (61cm)	24" (61cm)	ONLY $141.28/box (was $393.28/box) ONLY $119.88/box (was $195.80/box) ONLY $108.50/box (was $176.23/box) ONLY $104.30/box (was $156.64/box)
    Bag Dimensions: 30" (76cm) wide x 36" (91cm) long X 0.004" (0.1mm) thick Minimum Order Quantity - 200 Bags
    1-4 5-9 10-24 25+	VCF-43036B VCF-43036B VCF-43036B VCF-43036B	4 mil (100µm)	30" (76cm)	36" (91cm)	ONLY $252.70/box (was $437.40/box) ONLY $214.13/box (was $367.13/box) ONLY $180.88/box (was $330.43/box) ONLY $179.55/box (was $293.70/box)

• Linqstat VCF T-Series (Compare to Velostat 1724)

  • No. of Rolls	Product Part No.	Dimensions (Thickness) x (Width) x (Length)			Price (USD$) per roll
    Roll Dimensions: 5" (13cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 5" (13cm) wide tube = 10" (25cm) Circumference = 3.2" (8cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40005T/2 VCF-40005T/2 VCF-40005T/2 VCF-40005T/2	4 mil (100µm)	5" (13cm)* *Total circumference is 10" (25cm)	150' (46m)	ONLY $35.35/roll ONLY $23.23/roll ONLY $20.20/roll ONLY $19.19/roll
    Roll Dimensions: 6" (15cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 6" (15cm) wide tube = 12" (30.5cm) Circumference = 3.8" (9.7cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40006T/2 VCF-40006T/2 VCF-40006T/2 VCF-40006T/2	4 mil (100µm)	6" (15cm)* *Total circumference is 12" (30.5cm)	150' (46m)	ONLY $39.90/roll ONLY $26.22/roll ONLY $22.80/roll ONLY $21.66/roll
    Roll Dimensions: 6" (15cm) wide x 500' (152m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 20 meters 6" (15cm) wide tube = 12" (30.5cm) Circumference = 3.8" (9.7cm) Diameter
    Per meter 1 - 4 5 - 9 10 - 24 25 +	VCF-40006T/m VCF-40006T/4 VCF-40006T/4 VCF-40006T/4 VCF-40006T/4	4 mil (100µm)	6" (15cm)* *Total circumference is 12" (30cm)	Per meter 500' (152m)	$3.00/m ($3.00/meter) $114.40 ($0.75/meter) $100.10 ($0.66/meter) $85.80 ($0.56/meter)
    Roll Dimensions: 8" (20cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 8" (20cm) wide tube = 16" (41cm) Circumference = 5" (12.7cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40008T/2 VCF-40008T/2 VCF-40008T/2 VCF-40008T/2	4 mil (100µm)	8" (20cm)* *Total circumference is 16" (41cm)	150' (46m)	ONLY $51.18/roll ONLY $33.63/roll ONLY $29.24/roll ONLY $27.78/roll
    Roll Dimensions: 10" (25cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 10" (25cm) wide tube = 20" (51cm) Circumference = 6.4" (16.1cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40010T/2 VCF-40010T/2 VCF-40010T/2 VCF-40010T/2	4 mil (100µm)	10" (25cm)* *Total circumference is 20" (51cm)	150' (46m)	ONLY $63.97/roll ONLY $42.02/roll ONLY $36.56/roll ONLY $34.73/roll
    Roll Dimensions: 12" (31cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 12" (31cm) wide tube = 24" (61cm) Circumference = 7.6" (19.3cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40012T/2 VCF-40012T/2 VCF-40012T/2 VCF-40012T/2	4 mil (100µm)	12" (31cm)* *Total circumference is 24" (61cm)	150' (46m)	ONLY $76.77/roll ONLY $50.45/roll ONLY $43.87/roll ONLY $41.67/roll
    Roll Dimensions: 36" (91.4cm) wide x 150' (46m) long X 0.004" (0.1mm) thick Minimum Order Quantity - 1 roll 36" (91cm) wide tube = 72" (183cm) Circumference = 22.9" (58.2cm) Diameter
    1 - 4 5 - 9 10 - 24 25 +	VCF-40036T/2 VCF-40036T/2 VCF-40036T/2 VCF-40036T/2	4 mil (100µm)	36" (91cm)* *Total circumference is 72" (183cm)	150' (46m)	ONLY $230.30/roll ONLY $151.34/roll ONLY $131.60/roll ONLY $125.02/roll

CAPLINQ also accepts orders by Corporate Purchase Order. Please Contact us to find out more.

DON'T LIKE THESE PRICES? This e-mail address is being protected from spambots. You need JavaScript enabled to view it what you will pay for what order quantity.

LINQSTAT™ VCF-Series is a black, carbon-filled, volume-conductive polyethylene film velostat alternative commonly used as a static control material in numerous semiconductor, electronics and Smartcard applications due to its easy-grounding nature. Examples of these applications include electrically conductive bags of protective sleeves for static-sensitive components, grounding mats or as interleavers between rolls of Smartcard (chipcard) modules.

Since they do not hold static charge when grounded, LINQSTAT is commonly used as waste container drum liners for holding explosive chemicals that could be ignited by a static-caused spark, or dry chemicals, that tend to cling to ordinary nonconductive static laden plastics.

The film and its conductivity are unaffected by humidity and age. The film is heat-sealable, flexible and offers exceptional abrasion resistance. The film gives good thermal stability and has outstanding chemical resistance. The conductive bags meet electrical requirements of the military specification MIL-P-82646A.

LINQSTAT has a standard thickness range from 65µm to 200µm (0.0025" to 0.008") and is available in sheeting, tubing, V-fold and C-fold versions. Roll lengths and widths vary depending on thickness and application. Other variations may be available.

• Chemical Susceptibility
  • Weak Acids: Resistant
  • Methanol: Resistant
  • Ethanol: Resistant
  • Isopronanol: Resistant
  • Kelones: Slow Attack
  • Weak Alkalines: Slow Attack
  • Hydrocarbons: Non-Resistant
• Technical Specifications

  • Material Type	: Carbon-impregnated Polyolefin
    Color	: Black Opaque
    Temperature Limits	: -45°C to 65°C (-50°F to 150°F)
    Heat Sealable	: Yes
    Volume Resistivity	: <500 ohm-cm
    Surface Resistivity	: < 31,000 ohms/sq.cm
    Static Decay	: < 2.0 sec.
    Shelf-Life	: Indefinite

• Technical Datasheets

  • TDS (English)	LINQSTAT™ VCF-Series Volume Conductive Film

Read more about LINQSTAT™ VCF-Series Tape on our LINQSTAT Blog.

• Product Nomenclature
  •
• Harmonization Code

  • Customs Harmonization Code: 3920.10.90.11

    Polyethylene Sheeting: Other Plates, Sheets, Film, Foil, Tape, Strip of Polymers of Ethylene (Non-cellular)

• Applications

  • It is most often used in the ordnance industry (an industry that deals with military equipment, specifically weapons and ammunitions) as waste container liners. It's easy to understand that ignitable ammunition and static charges don't mix well, so these LINQSTAT bags are great for these applications.

• 3M Velostat 1704
• 3M Velostat 1706
• 3M Velostat 1708

• LINQSTAT VCF-4xxxS-Series
  ie. LINQSTAT VCF-40009S/2
• LINQSTAT VCF-4xxxV-Series
  ie. LINQSTAT VCF-40054V/2
• LINQSTAT VCF-6xxxS-Series
• LINQSTAT VCF-8xxxS-Series

• 3M Velostat 2004
• 3M Velostat 2014

• LINQSTAT VCF-4xxxB-Series
  ie. LINQSTAT VCF-41824B

The information below is provided for a service, and uses typical material properties. These are intended to calculate approximate packaging dimensions and weight

• LINQSTAT VCF S-Series
  • Metric (SI)

    Length	Equal to film width. The fourth & fifth digits in the product code in inches
    	ie. LINQSTAT VCF-40036S/2 is 91.44 cm (36" x 2.54 cm/in.) long
    Width & Height	Equal to roll diameter and dependent on film thickness and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (101µm thick, 45.72m long) has 108mm diameter
    	ie. LINQSTAT VCF-4xxxxS/5* (101µm thick, 228.9m long) has 188mm diameter
    	ie. LINQSTAT VCF-6xxxxS/2* (152µm thick, 45.72m long) has 121mm diameter
    	ie. LINQSTAT VCF-6xxxxS/5* (152µm thick, 228.9m long) has 224mm diameter
    	ie. LINQSTAT VCF-8xxxxS/2* (203µm thick, 45.72m long) has 133mm diameter
    	ie. LINQSTAT VCF-8xxxxS/5* (203µm thick, 228.9m long) has 255mm diameter
    Weight	Dependent on film thickness, roll width and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (101µm thick, 45.72m long) is 7.0 gr/mm width of roll
    	ie. LINQSTAT VCF-4xxxxS/5* (101µm thick, 228.9m long) is 27.0 gr/mm width of roll
    	ie. LINQSTAT VCF-6xxxxS/2* (152µm thick, 45.72m long) is 9.5 gr/mm width of roll
    	ie. LINQSTAT VCF-6xxxxS/5* (152µm thick, 228.9m long) is 39.6 gr/mm width of roll
    	ie. LINQSTAT VCF-8xxxxS/2* (203µm thick, 45.72m long) is 12.0 gr/mm width of roll
    	ie. LINQSTAT VCF-8xxxxS/5* (203µm thick, 228.9m long) is 52.2 gr/mm width of roll

  • Imperial (English)

    Length	Equal to film width. The fourth & fifth digits in the product code in inches
    	ie. LINQSTAT VCF-40036S/2 is 36" long
    Width & Height	Equal to roll diameter and dependent on film thickness and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (4 mil thick, 150ft long) has a 4.3" diameter
    	ie. LINQSTAT VCF-4xxxxS/5* (4 mil thick, 750ft long) has a 7.4" diameter
    	ie. LINQSTAT VCF-6xxxxS/2* (6 mil thick, 150ft long) has a 4.8" diameter
    	ie. LINQSTAT VCF-6xxxxS/5* (6 mil thick, 750ft long) has an 8.8" diameter
    	ie. LINQSTAT VCF-8xxxxS/2* (8 mil thick, 150ft long) has a 5.2" diameter
    	ie. LINQSTAT VCF-8xxxxS/5* (8 mil thick, 750ft long) has 10.0" diameter
    Weight	Dependent on film thickness, roll width and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (4 mil thick, 150ft long) is 6.3 oz/in. width of roll
    	ie. LINQSTAT VCF-4xxxxS/5* (4 mil thick, 750ft long) is 24.2 oz/in. width of roll
    	ie. LINQSTAT VCF-6xxxxS/2* (6 mil thick, 150ft long) is 8.5 oz/in. width of roll
    	ie. LINQSTAT VCF-6xxxxS/5* (6 mil thick, 750ft long) is 35.5 oz/in. width of roll
    	ie. LINQSTAT VCF-8xxxxS/2* (8 mil thick, 750ft long) is 10.8 oz/in. width of roll
    	ie. LINQSTAT VCF-8xxxxS/5* (8 mil thick, 750ft long) is 46.8 oz/in. width of roll

• LINQSTAT VCF S-Series
  • Metric (SI)

    Length	Equal to film width. The fourth & fifth digits in the product code in inches
    	ie. LINQSTAT VCF-40036S/2 is 91.44 cm (36" x 2.54 cm/in.) long
    Width & Height	Equal to roll diameter and dependent on film thickness and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (101µm thick, 45.72m long) has 108mm diameter
    	ie. LINQSTAT VCF-4xxxxS/5* (101µm thick, 228.9m long) has 188mm diameter
    	ie. LINQSTAT VCF-6xxxxS/2* (152µm thick, 45.72m long) has 121mm diameter
    	ie. LINQSTAT VCF-6xxxxS/5* (152µm thick, 228.9m long) has 224mm diameter
    	ie. LINQSTAT VCF-8xxxxS/2* (203µm thick, 45.72m long) has 133mm diameter
    	ie. LINQSTAT VCF-8xxxxS/5* (203µm thick, 228.9m long) has 255mm diameter
    Weight	Dependent on film thickness, roll width and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (101µm thick, 45.72m long) is 7.0 gr/mm width of roll
    	ie. LINQSTAT VCF-4xxxxS/5* (101µm thick, 228.9m long) is 27.0 gr/mm width of roll
    	ie. LINQSTAT VCF-6xxxxS/2* (152µm thick, 45.72m long) is 9.5 gr/mm width of roll
    	ie. LINQSTAT VCF-6xxxxS/5* (152µm thick, 228.9m long) is 39.6 gr/mm width of roll
    	ie. LINQSTAT VCF-8xxxxS/2* (203µm thick, 45.72m long) is 12.0 gr/mm width of roll
    	ie. LINQSTAT VCF-8xxxxS/5* (203µm thick, 228.9m long) is 52.2 gr/mm width of roll

  • Imperial (English)

    Length	Equal to film width. The fourth & fifth digits in the product code in inches
    	ie. LINQSTAT VCF-40036S/2 is 36" long
    Width & Height	Equal to roll diameter and dependent on film thickness and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (4 mil thick, 150ft long) has a 4.3" diameter
    	ie. LINQSTAT VCF-4xxxxS/5* (4 mil thick, 750ft long) has a 7.4" diameter
    	ie. LINQSTAT VCF-6xxxxS/2* (6 mil thick, 150ft long) has a 4.8" diameter
    	ie. LINQSTAT VCF-6xxxxS/5* (6 mil thick, 750ft long) has an 8.8" diameter
    	ie. LINQSTAT VCF-8xxxxS/2* (8 mil thick, 150ft long) has a 5.2" diameter
    	ie. LINQSTAT VCF-8xxxxS/5* (8 mil thick, 750ft long) has 10.0" diameter
    Weight	Dependent on film thickness, roll width and roll length.
    	ie. LINQSTAT VCF-4xxxxS/2* (4 mil thick, 150ft long) is 6.3 oz/in. width of roll
    	ie. LINQSTAT VCF-4xxxxS/5* (4 mil thick, 750ft long) is 24.2 oz/in. width of roll
    	ie. LINQSTAT VCF-6xxxxS/2* (6 mil thick, 150ft long) is 8.5 oz/in. width of roll
    	ie. LINQSTAT VCF-6xxxxS/5* (6 mil thick, 750ft long) is 35.5 oz/in. width of roll
    	ie. LINQSTAT VCF-8xxxxS/2* (8 mil thick, 750ft long) is 10.8 oz/in. width of roll
    	ie. LINQSTAT VCF-8xxxxS/5* (8 mil thick, 750ft long) is 46.8 oz/in. width of roll
