Linqstat Electrically Conductive Plastic Sheeting
Product Series	Technical Specifications				Comments
Product Series	Surface Resitivity ohms per square	Thickness mm (mils)	Volume Resistance (no pressure) ohms	Density (g/cc)	Comments
Top of Page
Linqstat VCF-Series Low Level Conductivity Surface Resistance between 50,000 - 200,000 ohms per square (5 x 10⁴ Ω/sq - 2 x 10⁵ Ω/sq) Used for Antistatic Packaging, ESD Protection or as ESD Interleaver
Linqstat VCF-Series	50,000 - 200,000 ohms/square	0.05mm - 0.2mm (2mil - 8mil)	Not volume conductive	0.95 - 0.98 g/cc	Considered antistatic as opposed to conductive
Linqstat VCF-2S200K	<200,000 ohms/square	0.05mm (2mil)	Not volume conductive	0.95 g/cc	For applications requiring very thin sheeting
Linqstat VCF-4S200K-Series	<200,000 ohms/square	0.1mm (4mil)	Not volume conductive	0.95 g/cc	Used in applications requiring a heavy-duty anti-static packaging film. Not suitable for sensors, but may be suitable for EMI/RF shielding.
Linqstat VCF-8S200K-Series	<200,000 ohms/square	0.2mm (8mil)	Not volume conductive	0.95 g/cc	Used in applications requiring a heavy-duty anti-static packaging film. Not suitable for sensors, but may be suitable for EMI/RF shielding.
Linqstat VCF-3S100K-Series	<100,000 ohms/square	0.075mm (3mil)	Not volume conductive	0.98 g/cc	Used in smartcard manufacturing as an antistatic interleaver (500m roll) 3.5 mil (0.090mm) thick or 4.5 mil (0.115mm) thick rolls are also available
Linqstat MVCF-Series Medium Level Conductivity Surface Resistance between 1000 - 50,000 ohms per square (1 x 10³ Ω/sq - 5 x 10⁴ Ω/sq) Used for large pressure sensors or for EMI / RF Shielding
Linqstat MVCF-Series	1,000 - 50,000 ohms/square	0.1mm - 0.2mm (4mil - 8mil)	800-2,000 ohms	1.02 - 1.10 g/cc	Alternative to Velostat 1704/1706/1708 Series
Linqstat MVCF-8S50K-Series	<50,000 ohms/square	0.2mm (8mil)	2,000 ohms	1.05 g/cc	Used in shielding applications, medical electrodes and large scale pressure sensors. Direct Alternative to 3M Velostat 1708
Linqstat MVCF-4S50K-Series	<50,000 ohms/square	0.1mm (4mil)	800 ohms	1.05 g/cc	Used in shielding applications, medical electrodes and large scale pressure sensors. Slightly lower surface conductivity than 3M Velostat 1708.
Linqstat MVCF-8S10K-Series	<10,000 ohms/square	0.1mm (4mil)	Not volume conductive	1.05 g/cc	Used as shielding material or sensors depending on surface conductivity. Direct Alternative to 3M Velostat 1704
Velostat 1708	<35,000 ohms/square	0.2mm (8mil)	10,000 ohms	n/a	Data based on Caplinq's own internal test methods
Velostat 1704	<15,000 ohms/square	0.1mm (4mil)	5,000 ohms	n/a	Data based on Caplinq's own internal test methods
Linqstat XVCF-Series High Level Conductivity Surface Resistance less than 1000 ohms per square (<10³ Ω/sq) Used for TENS Electrodes, Digital Whiteboards, Pressure Sensors & Wearable Electronics
Linqstat XVCF-Series	<1000 ohms/square	0.07mm - 0.1mm (2.75mil - 4mil)	25-100 ohms	1.10 - 1.18 g/cc	Highly-loaded - our most conductive versions
Linqstat XVCF-4S500-Series	<500 ohms/square	0.1mm (4mil)	100 ohms	1.10 g/cc	Used for sensitive pressure sensor applications, high level EMI and RF shielding and medical applications like ECG and TENS electrodes.
Linqstat XVCF-3S500-Series	<500 ohms/square	0.076mm (3mil)	50 ohms	1.10 g/cc	Used for sensitive pressure sensor applications, high level EMI and RF shielding and medical applications like ECG and TENS electrodes.
Linqstat XVCF-3.5S200-Series	<200 ohms/square	0.089mm (3.5mil)	25 ohms	1.10 g/cc	Used for sensitive pressure sensor applications, high level EMI and RF shielding and medical applications like ECG and TENS electrodes.
Linqstat XVCF-3S150-Series	<150 ohms/square	0.076mm (3mil)			Under development
Linqstat XVCF-3S75-Series	<75 ohms/square	0.076mm (3mil)			Under development

Frequently Asked Questions

Can you make a custom (specific) conductivity, thickness or width?

One question we get very, very often is if we can offer products with a specific resistivity, conductivity, thickness or width. The answer to this question is yes and no. Yes, we can make custom conductivities between 200 ohms/sq and 200,000 ohms/sq. Thicknesses from 50um to 200um and widths up to 510mm. However, due to the manufacturing process, this typically requires a minimum order of approximately 300 kg which equates to roughly 100 rolls of 91cm length.

Due to the overwhelming popularity of these requests, we have adopted a policy whereby we request that customers wishing a specific conductivity, thickness or width to pay $1500 upfront towards the cost of the rolls to make a custom product not currently available online. All other customers are asked to order one of our currently available products.

I'm not sure which product will work, can I get samples of a few of them?

Another question we get very often (I guess that's why they are FAQs) is that customers are not sure if the product will work for their applications and the request to get a "Sample Kit". By popular demand, we have created sample kits of both electrically conductive and anti-static plastic films. Though these might be more expensive than the rolls themselves, it allows users to test a range of materials to see if it meets their specific requirements. Click this link to be take to our You will find a link to this below.Linqstat Sample Kits. Sorry, there are no substitutions.

Can you test X, provide data on Y, give me information about Z?

We try to put all the information we currently have available online. If the information you are looking for is not in the Product Selector Guide, on the Product Page, in Technical Data Sheet, in Learn More section or in a blog article, you can assume that it is not yet available. We can and do want to provide more data, but we need to charge laboratory time for this work. Our lab rates are $175/hr.

How do these products compare to 3M® Velostat® materials?

3M manufacture a family of products made of black, volume conductive plastics under the tradename Velostat®. Though the tradename Velostat belongs to 3M, the product itself is not under patent. This means that other companies are allowed to manufacture similar products with no conflict with 3M. Please click here to read the article on generic vs brand-name products.

Similar to Velostat, CAPLINQ offers a line of volume-conductive plastics under its LINQSTAT brand name. LINQSTAT VCF is a black, carbon-loaded, electrically-conductive plastic. Unlike Velostat, CAPLINQ's product line is far more extensive, offering far more grades than 3M with different conductivity levels to give a better balance of price vs performance for your specific application. Compare the technical properties of your Velostat® Film to those found in the table below and on CAPLINQ's respective LINQSTAT Technical Datasheets.

I want to laminate the film to PVC. Do you provide conductive films with precoated Acrylic adhesives?

We don't provide electrically conductive films with any adhesives at all. Films are all "as is" with no backings or coatings. On the same note we do not sell corona, flame or plasma pretreated rolls with enhanced surface energy.

Do you sell any compatible adhesives?

We don't provide Polyethylene compatible adhesives. PE surface tension is very low so it is quite challenging to reach proper adhesion. Heat sealing is usually the best option but you can always consider corona, plasma or flame treating the films to achieve proper bonding with more standardized acrylic adhesives and processes.

What is the surface resistivity tolerance?

We can assure you that the surface resistivity will always be lower than the stated property. We have various films ranging from 250 up to 200000 ohms/sq so pick the one closer to your needs. Linqstat is not meant for very narrow requirements.

What is the difference between VCF, MVCF and XVCF

The main difference between these product lines is the surface resistivity. XVCF are our most carbon loaded films and can go as low as 250 ohms/sq. We do have experimental options that can go as low as 50 ohms/sq but due to the complete change to the polymer structure the cost difference is so high (almost tenfold) that doesn't justify mass production. In need of something like that? Contact us.

Learn More

Antistatic vs Electrically Conductive Plastics

Few plastic resins are inherently conductive, so it is necessary to modify the plastic in one way or another to make the plastics conductive. There are several ways to make a plastic conductive, among them the most important are as follows:

Filler Type: The most common filler type used to make plastics electrically conductive is carbon black. This is the filler used in LINQSTAT VCF, MVCF and XVCF-Series Conductive Plastics.
Filler Quantity: By increasing the filler percentage used, the conductivity of the plastic goes up. Up until a 15% filler loading, the plastics have enough conductivity to be considered antistatic, but a loading above 20% is normally needed to get electrically conductive properties and to bring the surface resistance down below 10,000 ohms per square.
Particle Size: The finer the particles of carbon used, the more densely packed these become in the plastic, and thus the better conductivity achieved. This must be balanced to be able to still process the plastic effectively and get a good dispersion.
Polymer Type: Different plastics have different densities and properties and can help or hurt the conductivity of the plastic, all other things being equal.

Compare Electrically Conductive Plastics

Electrically conductive plastics are carbon-filled and come in a range of surface resistances. These different conductive plastics come also in a range of thicknesses and widths. Our electrically conductive plastic comparison tool can help you choose the right conductive plastic for your application.

Conductive Plastic Compare Tool
