ABchimie 9005UV LED Glue

Harmonization Code : 3906909090 | Acrylic polymers in primary form Others>Others

Main features

One-component
Fast UV LED Curing
Glass to multiple substrate adhesion

Product Description

ABChimie® 9005UV LED Glue is a clear glue designed for the bonding of glass to multiple substrates, including glass, metals, and plastics. It is optically clear and doesn't experience yellowing. ABChimmie 9005UV LED Glue is ideal for applications requiring adhesion to glass and other substrates and optical transparency.

ABChimie 9005UV LED Glue is a urethane acrylate-based product with excellent adhesion to various substrates, especially glass. It cures rapidly under UV LED light (395 nm), has zero VOCs, and can be applied to high-speed manufacturing processes to increase productivity. ABChimmie 9005UV LED Glue is in full compliance with REACH and RoHS regulations.

Product Key Features

Transparent urethane acrylate glue
No yellowing
Allows for thick, controlled application
Fast UV cure (LED) for high-speed processing
Solvent-free formulation (no VOCs)

Applications

Components requiring optical transparency ex. glass, lenses, transparent covers.
Adhesion of glass to various substrates, ex. glass to metal, glass to plastic, glass to glass etc.
Laminated glass to glass ex. touchscreens, sensors
Gap filling and bonding
Printed circuit assemblies.

Product Family
ABC-9005UVLED

1. Select Package Type

5kg Bulk 1kg Bulk

Catalog Product

Unlike other products we offer, the products listed on this page cannot currently be ordered directly from the website.

Shortest leadtime

Shipping in 8 weeks

Contact for Pricing

Packaging

TDS, SDS & Technical documents

Specifications
Additional Information

Technical Specifications

General Properties
Appearance Appearance Appearance at room temperature.	Transparent
Physical Properties
Viscosity Viscosity Viscosity is a measurement of a fluid’s resistance to flow. Viscosity is commonly measured in centiPoise (cP). One cP is defined as the viscosity of water and all other viscosities are derived from this base. MPa is another common unit with a 1:1 conversion to cP. A product like honey would have a much higher viscosity -around 10,000 cPs- compared to water. As a result, honey would flow much slower out of a tipped glass than water would. The viscosity of a material can be decreased with an increase in temperature in order to better suit an application	50 - 80000 mPa.s
Mechanical Properties
Adhesion Strength Adhesion Strength Adhesion is the bond strength measurement of a coating to a substrate. When an adhesive is bonded to an item or surface, numerous physical, mechanical and chemical forces come into play, which may have an effect on each other.	6962 Oz/in

Additional Information

Frequently Asked Questions About ABChimie® 9005 UV LED

What are typical applications for ABChimie® 9005 UV LED?

ABChimie® 9005 UV LED is an LED UV-curable glue designed for the bonding and protection of printed circuit board assemblies (PCBs) and electronic components in demanding manufacturing environments, including:

Automotive electronics (e.g., control units, sensors)
Industrial automation (e.g., motor drives, PLCs)
Consumer electronics (e.g., smart devices, wearables)
Other high-reliability electronic assemblies

Why choose ABChimie® 9005 UV LED?

ABChimie® 9005 UV LED delivers rapid UV curing, excellent electrical insulation, is colorless, and has strong adhesion to various substrates. It supports high-throughput manufacturing while providing durable protection for sensitive components.

What is the shelf life of ABChimie® 9005 UV LED?

ABChimie® 9005 UV LED has a shelf life of 12 months when stored at 5–30°C in tightly sealed, opaque containers. The product must be sealed away from excessive heat (>40°C). Before use, allow the product to equilibrate for 24 hours at 18–32°C for optimal performance. Due to settling, glue should be mixed before use.

What happens after the shelf life?

Using ABChimie® 9005 UV LED past its shelf life may alter viscosity, affecting uniformity and application performance. Always use an in-date product for reliable results.

What is the recommended curing method for ABChimie® 9005 UV LED?

ABChimie® 9005 UV LED is UV-curable and should be cured with a mercury lamp. The minimum UVA dose is 500 mJ/cm² for a 100 μm thickness. The mercury lamp-curable version is ABChimie® 9005 UV. Higher UVA doses do not negatively affect final properties.

What safety precautions should I take?

Use ABChimie® 9005 UV LED in a well-ventilated area, avoid skin and eye contact, and follow all Safety Data Sheet (SDS) guidelines. Keep away from open flames and sparks.

Can I adjust viscosity?

ABChimie® 9005 UV LED can be customized for variable viscosities. Contact our team for guidance.

Learn More About ABChimie® 9005 UV LED

ABChimie® 9005 UV LED is a proven solution for engineers seeking fast, reliable protection of electronic assemblies in demanding manufacturing environments. This UV-curable glue delivers rapid curing, excellent electrical insulation, and strong environmental resistance—ideal for applications in automotive electronics, industrial automation, consumer electronics, and other high-reliability assemblies.

Main Advantages of ABChimie 9005 UV LED

UV Curing

ABChimie® 9005 UV LED cures rapidly under UV light, enabling integration into both batch and inline production. The resin forms a durable, high-performance layer that protects assemblies while supporting high-throughput manufacturing.

MECHANICAL PROTECTION

ABChimie® 9005 UV LED provides excellent mechanical protection. The hardness helps resist scratches, abrasion, and minor impacts, ensuring long-term stability of encapsulated components.

no yellowing

ABChimie® 9005 UV LED is formulated to resist yellowing over time, maintaining clarity and optical integrity even after prolonged UV exposure. This ensures that encapsulated components or coatings remain visually clear and do not discolor, ideal for displays, optical devices, and other applications where long-term transparency is critical.

EXCELLENT ADHESION on many substrates, especially glass

ABChimie® 9005 UV LED bonds strongly to glass substrates, providing reliable adhesion on smooth, non-porous surfaces. This ensures durable protection for components mounted on or encapsulated against glass, making it well suited for applications such as displays, sensors, optical assemblies, and glass-based electronic modules.

How to Choose a Resin

Selecting the most suitable resin requires consideration of key factors:

✔ Norms & Compliance
✔ Environment / Exposure Conditions
✔ Repairability
✔ Electrical Performance
✔ Application Method
✔ Operating Temperature

Compliance You Can Trust ✅

ABChimie® 9005 UV LED meets stringent industry standards, ensuring reliability and regulatory adherence for OEMs and contract manufacturers:

REACH Compliant
RoHS 2011/65/EU Compliant

Curing Tip: ABChimie 9005 UV LED cures with UV rays. It is crucial to use the appropriate equipment, as well as the recommended settings, to achieve the best properties of the resin.
