HB3 | Quartz Sand 99.97%


Main features
  • ≥99.97% SiO2
  • High purity
  • Flexible Particle Size

Product Description

HB3 Quartz sand Silica is produced from chemically treated and water washed high purity quartz. The milling process ensures minimal contamination, resulting in high purity silica sand of up to a SiO2 content of 99.97%.

HB3 Quartz sand Silica is an inherently inert white product, with low moisture, commonly used in the outer lining of crucibles and quartzware. The silica sand is tested and controlled to rigorous standards which ensure consistent chemical and physical properties resulting in predictable and repeatable performance.



Product Family
QS-HB3
1 Ton Bulk bag

No longer available

This product is no longer available or will become obsolete soon. Please contact us so we can recommend an alternative product.

Technical Specifications

Chemical Properties
Silicon Dioxide(SiO2) 99.97 %
Other Properties
Metallic Impurities
Aluminum (Al)
Aluminum (Al)
Aluminium is a metallic element with a silvery-white, soft nonmagnetic, ductile elements that has a melting point of 660.3 C
50 ppm (max)
Chromium (Cr)
Chromium (Cr)
Chemical element with a steely-grey, hard and brittle metal, resists tarnishing and has a high melting point.
0.10 ppm (max)
Copper (Cu) 0.10 ppm (max)
Iron (Fe)
Iron (Fe)
A chemical element with a melting point of 1,538 C
15 ppm (max)
Magnesium (Mg) 1 ppm (max)
Potassium (K) 20 ppm (max)
Sodium (Na) 30 ppm (max)

Additional Information

Particle Size Analysis

Microns % Finer
250 99.5
200 75
180 50
125 20
100 3











Typical Values. They do Not Represent A Specification
