Antistatic Tapes
LINQtape Polyimide Tapes include a series of Anti-Static Tapes and films with an anti-static polymer coating on top of the polyimide layer. These anti-static tapes have a surface resistance of 1x1012 ohms per square.
LINQtape ESD products are high-temperature resistant, antistatic treated polyimide films coated with acrylic or silicone adhesive. They are designed for both masking and temporary bonding in many high temperature applications found in semiconductor, electronic, automotive and other general manufacturing industries.
Our antistatic product line up provides an excellent balance of electrical, mechanical, thermal, and chemical properties over a wide range of temperatures. It has enhanced strength for puncture and tear resistance and can be used in applications that may see high intermittent temperatures.
PIT1A-ESD | 1mil Antistatic ESD Polyimide (Kapton) Tape with Acrylic Adhesive
- 1 mil polyimide film
- Non-silicone, acrylic adhesive
- >6500V breakdown voltage
- In stock
PIT1A-ESD-B | 1 mil Black XC ESD Conductive Polyimide (Kapton) Tape with Acrylic Adhesive
- 1 mil polyimide film
- Non-silicone, acrylic adhesive
- Antistatic Polymer Coating
- In stock
PIT1A-ESD-BRL | 1 mil Black Conductive ESD Tape with Acrylic Adhesive & Release liner
- 1 mil polyimide film
- Acrylic adhesive with release liner
- Antistatic Polymer Coating
- 2 weeks
PIT1S-ESD | 1-mil Antistatic ESD Polyimide (Kapton) Tape with Silicone Adhesive
- 1 mil polyimide film
- Silicone adhesive
- >5500V breakdown voltage
- 2 weeks
PIT1S-ESD-DCD | 1 mil Die Cut ESD Polyimide (Kapton) Tape with Silicone Adhesive | Single side Discs
- 1 mil polyimide film
- Single side Silicone adhesive
- Die cut Discs
- 2 weeks
Product Selector Guide
Product name | Description | Adhesive type | Adhesive thickness | Polyimide thickness | Total thickness | Peel Strength (N/25mm (oz/in)) | Dielectric strength (kV/mm) |
---|---|---|---|---|---|---|---|
PIT1A-ESD | 1mil Antistatic ESD Polyimide (Kapton) Tape with Acrylic Adhesive | Acrylic | 1.5mil (38µm) | 1mil (25.4µm) | ±2.5mil (63.5µm) | 7.1 (26) | 236 |
PIT1S-ESD | 1-mil Antistatic ESD Polyimide (Kapton) Tape with Silicone Adhesive | Silicone | 1.5mil (38µm) | 1mil (25.4µm) | ±2.5mil (63.5µm) | 5.2 (19) | 236 |
PIT1A-ESD-B | 1 mil Black XC ESD Conductive Polyimide (Kapton) Tape with Acrylic Adhesive | Acrylic | 1.5mil (38µm) | 1mil (25.4µm) | ±2.5mil (63.5µm) | 6.9 (25) | 255 |
