LINQCELL GDL2900 | 2.9mm Carbon Plate

Harmonization Code : 6815.11.00.00 | Articles of stone or of other mineral substances, not elsewhere specified or included; Non-electrical articles of graphite or other carbon; Carbon fibres and articles of carbon fibres

Main features

2.9mm - 2900um - 114mil
Thickest GDL available
Graphitized Carbon Plate

Product Description

LINQCELL GDL2900 is a graphitized carbon plate, commonly used as a gas diffusion layer and electrode for fuel cells. Its through plane resistance is less than 25 mΩcm². It has a thickess of 2.9mm that is measured at 50 kpa.

LINQCELL GDL2900 has a density of ±0.60 g/cm³ and a through plane resistivity of 90mΩ-cm instead of 100mΩ-cm from the classic Spectracarb grades. Voltage loss is 28mV. Shortly, we should be able to die cut circles and most designs that you might require.

Product Family
GDL2900

1. Select Sheet Size

40 x 40 cm 53 x 30 cm

Catalog Product

Unlike other products we offer, the products listed on this page cannot currently be ordered directly from the website.

Shortest leadtime

Shipping in 8 weeks

In stock

Contact for Pricing

Packaging

TDS, SDS & Technical documents

Specifications

Technical Specifications

General Properties
Basis Weight Basis Weight Basis weight refers to the weight measured in pounds off 500 sheets of paper in that paper’s basic sheet size.	1734 g/m2
Density (g)	0.60 g/cm3
Total Thickness Total Thickness Total thickness is taking into account all the films, coatings, adhesives, release liners and special layers and is the maximum thickness of a film or tape.	2900 μm
Electrical Properties
TP Resistance TP Resistance Opposition to the flow of electric current.	24.5 mΩcm2
Through Plane Resistivity Through Plane Resistivity Resistance of the amount of current through a material	87.5 mΩcm
Voltage loss	27 mV
